Tinkerer Dmitry Grinberg recently unveiled an unexpected Linux-based operation system, but this one's got a twist! It's a PCB crammed with three integrated circuits, each nestled in an 8-pin SOIC package. But why all the fuss about humble 8-pin chips? Emulation, baby!
Two components are evident: a USB-to-serial chip and an SPI RAM chip. The star circuit is an STM32G0 series device, packing a zippy ARM Cortex M0+ core. This powers a MIPS emulator, a familiar face in a previous project. With a 148 MHz clock, it zips along at approximately 1.4 MHz, which, surprisingly, is just enough to run a fully-fledged Debian system. No lean, stripped-down version here.
The hardware hacks required to cram serial, memory, and SD card functionalities onto so few pins are a sight to behold. The SD and serial share pins, with a filter in place to filter out the high-frequency SPI traffic, leaving room for the low-frequency serial traffic. Puzzling over possible applications for this diminutive machine is a fun pastime, but it remains a fascinating engineering feat nonetheless.
Diving Deeper
Unpacking the STM32G0
The STM32G0 series microcontrollers wield a Cortex-M0+ core, operating up to 64 MHz. They are designed for power efficiency and affordability, finding their place in various embedded systems. With limited memory (32 KB to 128 KB flash, up to 32 KB RAM) and peripherals (UART, SPI, I2C), they are far from Linux-capable out of the box.
The Linux Dilemma
With its memory and processing constraints, it's no walk in the park to run Linux on the STM32G0 series. Linux demands significant resources in terms of memory and processing power. The STM32G0 simply doesn't have the muscle to manage a standard Linux environment.
Potential Solutions
Instead of attempting a full Linux emulation, developers may opt for a lightweight Real-Time Operating System (RTOS) or custom firmware designed for efficient STM32G0 usage. Alternatively, employing the STM32G0 as a gateway or proxy to interact with a Linux system elsewhere could offer Linux-like functionality, although not a true emulation. Lastly, for those intent on running Linux on a miniscule form factor, an FPGA (Field-Programmable Gate Array) alongside the STM32G0 might provide additional logic and processing, but it would add complexity and demand more hardware and design effort.
In conclusion, emulating a full Debian on an 8-pin SOIC-packaged PCB with an STM32G0 is a challenging endeavor. Instead, focus on lightweight RTOS options or external systems for Linux-inspired functionality.
This surprising project demonstrates the emulation of Linux on an STM32G0, a microcontroller typically not known for supporting such an operation system. Yet, with a 148 MHz clock, it manages to run a fully-fledged Debian system, despite being far from traditionally Linux-capable due to its limited memory and peripherals. The limitations necessitate alternatives like using a lightweight Real-Time Operating System, custom firmware, employing the STM32G0 as a gateway to interact with an external Linux system, or combining it with an FPGA for additional processing power.
