The reason for the widespread use of FR4 material in the process of PCB fabrication is its versatility and dependability.
The FR4 material, a popular choice in electronics, is primarily used as the substrate for printed circuit boards (PCBs) due to its desirable properties such as flame retardancy, durability, electrical insulation, mechanical strength, and thermal stability [1][4].
FR4 finds widespread application across various sectors, including consumer electronics, automotive electronics, LED lighting, industrial equipment, and advanced electronic designs. In general PCB manufacturing, FR4 serves as the backbone material, supporting prototyping and full-scale production due to its cost-effectiveness and reliable performance under typical electronic operating conditions [1][5].
In the realm of LED lighting, single-sided FR4 PCBs are often employed in LED strips and boards because they can withstand the moderate heat produced by LEDs while maintaining reliable electrical performance [2]. For automotive applications, FR4 PCBs are used where standard ranges of operating temperature (typically -40°C to 125°C) are required. Variants of FR4 with higher temperature resistance (up to 200°C) extend usage in more demanding environments [3].
Industrial and consumer electronics benefit from FR4's mechanical and chemical stability, making it suitable for products where flame retardant benefits and mechanical strength are important [1][4]. Advanced FR4 materials also serve in more complex, high-density boards including those with laser drill processing, supporting wireless capabilities and higher reliability factors in electronic devices [5].
FR4 materials offer low moisture absorption (0.10% when immersed in water for 24 hours), making them water-resistant. They have a wide range of operating temperatures (50°C to 115°C), and their thermal stability ensures that they can withstand moderate heat production in various applications [1][4].
However, FR4 is not the ideal choice for controlled impedance boards due to Dk variations. It is also not the best material for boards operating at high frequencies or in harsh situations [1].
Examples of high-performance FR4 materials include Isola 370HR, which is suitable for applications with operating temperatures exceeding 150°C due to their better thermal performance and low expansion rates [6].
In the manufacturing process, foreign materials, whether conductive or non-conductive, can be detected in raw (B-stage) laminate. Translucent particles trapped inside the PCB are permissible in all classes, provided that the electrical and thermal properties of the board are not affected [7]. Weave exposure, where unbroken woven cloth fibers on the surface are not entirely covered by resin, is acceptable in all classes of boards, provided that the remaining space between conductors meets the minimum spacing requirement [7].
Certain phenomena, such as measling and crazing, can develop during the lamination process. Measling, the presence of discrete white spots in the base material, occurs when the resin is not optimally applied. It is permissible in all applications except for high-voltage products, but excessive measling might decrease the board's electrical and overall performance [7]. Crazing is a phenomenon wherein a series of connected white spots or crosses appear in the base material, indicating the separation of glass cloth fibers and connecting weave junctions. The distance between adjacent crazing patterns should not be more than 50% of the distance between adjacent conductive patterns in classes 2 and 3 boards [7].
Delamination/blister is any planar separation on a circuit board, such as between plies inside a base material, or between material and conductive foil. In class 1, the area of the board affected by delamination does not exceed 1% of the total area, and the blister or delamination should be less than 25% of the distance between conductors. In classes 2 and 3, the same rules apply. Delamination should not be closer to the edge of the board [7].
FR4 materials are cost-friendly when compared to other materials, making them a popular choice for a wide range of applications in the electronics industry. Despite their limitations in certain areas, their versatility, durability, and cost-effectiveness make them an essential component in the production of printed circuit boards.
